Description
Weatherized, 70/100v permanent installation version of the SX300E, a 12“ composite two-way considered to be the world‘s best lightweight, high power speaker system. Designed for distributed systems.
Chassis Size: 304.8 mm (12")
Color: White
Directivity Index: 11.1 dB
Input Connections: Four-pin Speakon (2)
Speaker Type: Fullrange
Speaker Type: Mid-High
Speaker Type: Two-Way
Frequency Response (-10 dB): 50 - 20000 Hz
Internal Crossover: Yes
Sensitivity 1 W/1 m: 99 dB
Max. SPL/1m (calc): 131 dB
Coverage (Nominal -6 dB) H: 65 °
Coverage (Nominal -6 dB) V: 65 °
System Power Handling: 300 Watts
LF Transducer: DL12BFH
HF Transducer: DH2010
Crossover Frequency: 1500 Hz
Nominal Impedance (Passive): 8 ?
Minimum Impedance: 6 ?
Flying: Yes
Outdoor: Yes
Height: 586 mm (23.07")
Width: 429 mm (16.89")
Depth: 312 mm (12.28")
Weight Net: 14.5 kg (31.97 lbs)
- Vented LF enclosure
- 1.25” voice coil (titanium diaphragm)
- High Sensitivity
- Ultra-linear frequency response
- Integral 70/100V transformer
- PRO™ Driver protection circuit
- HF-horn features Varipath™
- Trapezoidal (25° per side)
- 4 x M8x1.25 attachment inserts
