Description
Clear, powerful, and musical, the Live X series was born to command the stage for professional music performance. Available in both powered and passive versions, Live X loudspeakers offer top-quality components in remarkably affordable configurations that put the EV-quality experience within reach for artists, engineers, and live-sound businesses. Designed for a wide range of portable sound applications, Live X loudspeakers are housed in hardy stackable enclosures of solid wood, making them lighter than comparable-quality composite or plastic boxes and therefore easier to load, transport, and set up. With high output, extended frequency range, and high sensitivity, Live X loudspeakers are clean, flat, and hot, making music of all kinds sound its best. The Live X series is serious gear for serious sound.
Speaker Type: Full-range, two-way
Frequency Response (-3 dB): 62 - 18000 Hz
Frequency Response (-10 dB) 55 - 20000 Hz
Max. SPL/1m (calc): 137 dB
Coverage (Nominal -6 dB) H: 90 °
Coverage (Nominal -6 dB) V: 50 °
System Power Handling: 600W Cont., 2400W Peak
LF Transducer: (2) EVS-15K, 381mm (15") Woofers
HF Transducer: DH-1K, 39mm (1.5") Titanium Diaphragm Compression Driver
Nominal Impedance: 4 ?
Connector Type: Parallel Neutrik® NL4
Weight Net: 52 kg (114.64 lbs)
- High-volume punch and ultra-wide frequency response
- Ideal for mains
- Two EVS-15K woofers for extended LF
- Braced 15mm plywood enclosure
- Black textured finish
- 1.5-inch DH-1K titanium HF compression driver
- 38 Hz – 20 kHz frequency range
