Description
ZX1 is a high-performance, compact loudspeaker with a lightweight, durable, high-tech enclosure engineered to provide maximum rigidity and acoustic performance.
Chassis Size: 203.2 mm (8")
Color:
Input Connections: Parallel Neutrik® NL4
Speaker Type: Fullrange
Speaker Type: Mid-High
Speaker Type: Two-Way
Speaker Type: Wedges
Frequency Response (-3 dB): 60 - 20000 Hz
Frequency Response (-10 dB): 48 - 20000 Hz
Internal Crossover: Yes
Sensitivity 1 W/1 m: 94 dB
Max. SPL/1m (calc): 123 dB
Coverage (Nominal -6 dB) H: 90 °
Coverage (Nominal -6 dB) V: 50 °
Rotatable Horn: Yes
System Power Handling: 200 Watts
LF Transducer: EV8L
HF Transducer: DH2005
Nominal Impedance (Passive): 8 ?
Outdoor: No
Height: 451 mm (17.76")
Width: 282 mm (11.1")
Depth: 263 mm (10.35")
Weight Net: 8.4 kg (18.52 lbs)
- EV8L high performance 8” woofer
- Exclusive port design for extended LF response
- 200W cont., 400W program power handling
- Integrated overload protection
- DH2005 true compression driver (1,25” voice coil)
- Rotatable 90 x 50 HF horn
- Integrated monitor angle
- Integrated pole-mount adapter and handle
- 4 metric inserts for additional mounting options
- 2 Neutik NL4 connectors
