Description
Compact and portable performance. Provides the low frequency energy needed to keep up with Tour X top boxes. Integrated low-pass input filter for single amp drive.
Color: Black
Input Connections: Parallel Neutrik® NL4
Speaker Type: Subs
Frequency Response (-3 dB): 50 - 160 Hz
Frequency Response (-10 dB): 45 - 700 Hz
Internal Crossover: Yes
Recommended High-Pass Frequency: 30 Hz
Sensitivity 1 W/1 m: 100 dB
Max. SPL/1m (calc): 132 dB
System Power Handling: 500 Watts
LF Transducer: EVS18S
Nominal Impedance (Passive): 8 ?
Minimum Impedance: 7.5 ?
Enclosure Material: Plywood and MDF with EVCOAT
Flying: No
Height: 769 mm (30.28")
Width: 508 mm (20")
Depth: 591 mm (23.27")
Weight Net: 33.8 kg (74.52 lbs)
- EVS-18S 18” (457 mm) LF transducer
- 100 dB sensitivity, 132 dB maximum SPL
- Integrated low pass filter with 6 dB / octave slope
- 500 W continuous, 2000 W peak power handling
- Pole mount to elevate a two-way loudspeaker
- Mounting points to attach optional TX-W1 wheel kit
